Large display

Large display for Norm signal, PT-100, frequency, counter, Profibus, BCD, RS-232, RS-485

The MG-… is a numeric LED display for measuring various measurement signals such as voltage / current, Temperature and frequency. The configuration takes place via three front buttons or with the optional PC software PM-TOOL. An integrated program lock prevents unwanted changes to parameters and can easily be unlocked again using an individual code. With the two integrated normally open contacts, limit values can be monitored and reported to a higher-level control room. An analog output, an RS232 or RS485 interface and a transmitter supply are optionally available for further evaluation. The ALU profile housing used is designed for rough industrial use and is available as a surface-mounted and control panel version.

Technical specifications

Digit heights: 57 mm, 100 mm und 200 mm

Colours: red, green, amber

Designs: single-line, multiline, indoor, outdoor

Type of display: numeric (LED)

Protection class: Standard IP65

Measuring inputs: 0… 10 V, 0… 50 mV, 0/4… 20 mA, Pt100 3-wire, Thermocouple type L, J, K, B, S, N, E, T, R,

Frequency 0… 10 kHz, NPN 0… 3 kHz, PNP 0… 1 kHz, Speed 0… 9999 1 / min, Counter 0… 9999 (prescaler up to 1000), RS-232, RS-485, Profibus

CheckOptional with calibration
