156 – Cable sensor

Temperature sensor is standard cable element version without process connection.

The 156 series cord elements are insertion probes with a fixed mounted connection cable, available in various standard diameters and cable types. Standard PT100 and various thermocouples are possible as measuring system, with more specific sensors in PT200, PT500, PT1000, Ni100 and Ni1000. These cord sensors are suitable for all kinds of applications in, for example, Industry, Greenhouse construction, Oven construction, Climate technology or Machine construction. Connection cable possible in PVC, PUR, Silicone, PTFE or Glass side for temperatures up to 600 ° C. Optionally, an anti-kink spring can be fitted to the cable outlet.

Technical specifications

Measuring element: PT100, PT200, PT500, PT1000, Ni100, Ni1000, Thermocouple J and K

Measuring system: Single or Duplex version in 2, 3 or 4-conductor technology

Material: SS-316

Dimensions: As stated when ordering

Process connection: none

Connection cable: materials / temperature range

  PVC / max. 80 °C

  PUR / max. 70 °C

  Silicon / max. 180 °C

  PTFE / max. 250 °C

  Glassilk/ max. 600 °C

  Standard length 2 meters (specify other lengths when ordering)

CheckOptional with calibration
