INFRARED TEMPERATURE SENSORS
	for a flyer click >>>
For many different purposes can infrared temperature sensors be supplied. Below you find an overview, custom solutions on demand. Table of Emissivity
	Temperature range:	Spectrum range:	Application:	Detector:	Alignment:	Spot:	Exposition time:

PI	-20° - 900°C	7,5-13 µm	On-line Watch the movie	Uncooled FPA - Bolometer	Video		100 Hz

CX - CXhs	-30° - 900°C -30° - 150°C	8-14 µm	Industrial		-	0,6 mm 0,8 mm	150 ms

CT	-40° - 900°C	8 - 14 µm	Plastics Organic materials Rubber Paper Lacquers Asphalt Food	Thermokette	-	2:1 15:1 22:1	150ms

CT fast	-40° - 600°C	8 - 14 µm	Plastics Organic materials Rubber Paper Lacquers Asphalt Food	Thermokette	-	10:1	9ms

CT 2M	250° - 1600°C	1 - 1,6 µm	Metal Laser Glass Graphite Ceramiek	InGaAs	-	150:1 330:1	1ms

CT 3M	50° - 600°C	2,3 µm	Metal Laser Glass Graphite Ceramiek	PbSe	-	40:1 100:1	1ms

CT-hot	-40° - 975°C	8 - 14 µm	Plastics Organic materials Rubber Paper Lacquers Asphalt Food	Thermokette	-	2:1 10:1	100ms

CT-G5	100 - 1650°C	5,2 µm	Glass from 100 to 1650°C		-	10:1 (G5L) 20:1 (G5H)	80 ms

CT-XL3M	100 - 600°C	2,3 µm	laser material processing, laser welding and laser soldering		-	100:1	1 ms

CT-RATIO	700°C - 1800°C	0,7 µm 1,1 µm	Steel applications Watch the movie		Laser	80:1	5 ms

CT-7P	0 - 500°C	7,9 µm	Plastics		-	10:1	150 ms

Metis MB35	50° - 700°C 100 ° - 1000°C	2 - 5 µm	Metals Glue-purely Brake disks Plastics Temp. of tempering	PbSe	Laser Visier	1,6mm	3ms

Metis MI16	200° - 1300°C 300° - 1300°C 300° - 2500°C 350° - 1800°C	1,45 - 1,8 µm	Metals Laser applications	InGaAs	Laser Visier Video	0,35mm	1ms

Metis MI18	120° - 550°C 160° - 800°C	1,45 - 2,1 µm	Metals Laser applications Plastics Temp. of tempering	InGaAs	Laser Visier Video	0,7mm	1ms

Metis MP23	130° - 700°C	2,0 - 2,6 µm	Metals Temp. of tempering	PbS	Laser Visier	0,6mm	3ms

Metis MP25	75° - 550°C 100° - 700°C 160° - 1200°C 200° - 1300°C	2,0 - 2,8 µm	Metals Glass of melt Graphite Molten baths	PbS	Laser Visier	0,25mm	3ms

Metis MQ11	600° - 1300°C 750° - 1800°C 900° - 2500°C	0,7 - 1,1 µm	Metals Glass of melt Graphite Molten baths	Si / Si	Laser Visier Video	0,5mm	2ms

Metis MS09	550° - 1400°C 650° - 1800°C 750° - 2500°C 1000° - 3300°C	0,7 - 1,1 µm	Metals Glass of melt	Si	Laser Visier Video	0,35mm	1ms

Metis MY34	300° - 1300°C	3,43 µm	Glass interior Tempertures Wafer	Pyroelektr.	Laser Visier	1,5mm	100ms

Metis MY39	200° - 1000°C 500° - 2000°C	3,95 µm	Temp. by flames Glass interior	Pyroelektr.	Laser Visier	1,5mm	100ms

Metis MY51	100° - 1000°C 300° - 1300°C 500° - 2500°C	5,14 µm	Glass Glass surfaces	Pyroelektr.	Laser Visier	0,8mm	10ms 40ms 100ms

Metis MY68	50° - 400°C	6,85 µm	Plastic foils	Pyroelektr.	Laser Visier	5mm	100ms

Metis MY80	50° - 400°C	8,05 µm	Foils Plastics Glass	Pyroelektr.	Laser Visier	2,5mm	100ms

Metis MY81	0° - 400°C 0° - 800°C 0° - 1000°C	8 - 10 µm	Plastics Non metals	Pyroelektr.	Laser Visier	1,2mm	5ms 40ms 100ms

Metis MY84	0° - 400°C 0° - 700°C 0° - 1000°C	8 - 14 µm	Organic materials Rubber Paper Lacquers	Pyroelektr.	Laser Visier	0,9mm	5ms 40ms 100ms

Polaris PI16	300° - 1300°C 350° - 1800°C	1,45 - 1,8 µm	Thermal relay	InGaAs	Laser	2mm	4ms

Polaris PS09	550° - 1400°C 650° - 1800°C	0,7 - 1,1 µm	Thermal relay	Si	Laser	2mm	4ms

Sirius SI16	250° - 1000°C 300° - 1300°C 350° - 1800°C	1,45 - 1,8 µm	Metals Laser applications	InGaAs	Laser	2mm	5ms

SiriusSS09	550° - 1400°C 650° - 1800°C	0,7 - 1,1 µm	Metals Glass of melt	Si	Laser	2mm	5ms

CT Laser	-40° - 975 °C	8 - 14 µm	Metals Semiconductor Plastics Glass Through flames Flame temperature	Thermokette	Laser	50:1 75:1	9ms 120ms

CT Laser 1M / 2M	250° - 1600°C	1 - 1,6 µm	Metal Laser Glass Graphite Ceramiek	InGaAs	Laser	150:1 330:1	1ms

CT Laser 3M	50° - 600°C	2,3 µm	Metal Laser Glass Graphite Ceramiek	PbS	Laser	40:1 100:1	1ms

CT Glass	100° - 1600°C	5,2 µm	Glass	Pyroelektr.	Laser	45:1 70:1	80ms 120ms

CS	-20° - 350°C	8 - 14 µm	OEM Watch the movie	Thermokette	-	1,2mm	30ms

CS micro	-20° - 350°C	8 - 14 µm	OEM	Thermokette	-	1,2mm	30ms

CS micro 2W	-30° - 900°C	8 - 14 µm	OEM	Thermokette	-	1,2mm	150ms

CSm hs	-30° - 150°C	8 - 14 µm	OEM	Thermokette	-	0,8mm	150ms

CSmed	-20° - 350°C	8 - 14 µm	OEM	Thermokette	-	1,2mm	30ms

CT Ex	-40° - 900°C	8 - 14 µm	Plastics Organic materials Rubber Paper Lacquers Asphalt Food	Thermokette	-	0,6mm	150ms

Blackbody	up to 400°C
